Specifications
| 1/1.8”, 4.0 megapixel, progressive scan, CMOS | sensor |
| 4.0mm@F1.0 | Lens |
| Lens (mm):4/Detect (m) :62.1/Observe (m) :24.8/Recognize (m) :12.4/Identify (m):6.2 | DORI Distance |
| 103.0° | Angle of View (H) |
| 69.2° | Angle of View (V) |
| 134.6° | Angle of View (O) |
| Tilt: 0°~90°/ Rotate: 0°~360°/Pan:0° ~ 360° | Adjustment angle |
| Auto/Manual, 1 ~ 1/100000s | Shutter |
| Colour: 0.005Lux (F1.0, AGC ON)/0Lux with IR | Minimum Illumination |
| IR-cut filter with auto switch (ICR) | Day/Night |
| 2D/3D DNR | Digital noise reduction |
| 56db< | S/N |
| 30-40m IR range | IR Range |
| 2 | LEDs Number |
| 850nm | Wavelength |
| Auto/Manual | IR On/Off Control |
| Digital Defog | Defog |
| 120dB | WDR |
| Ultra 265, H.265, H.264, MJPEG | Video Compression |
| Baseline profile, Main Profile | H.264 code profile |
| Main Stream: 4MP (2688*1520), Max 30fps;4MP (2560*1440), Max 30fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; |
Frame Rate |
| 128 Kbps~16 Mbps | Video Bit Rate |
| Supported | HLC |
| Supported | BLC |
| Up to 8 OSDs | OSD |
| Up to 4 areas | Privacy Mask |
| Up to 8 areas | ROI |
| Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 | White Balance |
| Audio detection, Deep Learning, Cross Line, Enter Area, Leave Area, Intrusion, People counting, People Flow counting, Crowd Density Monitoring, Face Capture (Maximum 8) |
Smart Features |
| Watermark, IP Address Filtering, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
General Function |
| Support | Smart illumination |
| Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise | Flip |
| G.711 | Audio Compression |
| 64 Kbps | Audio Bitrate |
| Supported | Suppression |
| 8KHZ | Sampling Rate |
| Micro SD, up to 256GB | Edge Storage |
| ANR,NAS(NFS) | Network Storage |
| IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, QoS |
Protocols |
| ONVIF (Profile S, Profile T), API | Compatible Integration |
| Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below | Web Browser |
| Up to 32 users. 3 user levels: administrator, operator and common user | User/Host |
| Password protection, strong password, HTTPS encryption, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF |
Security |
| 1 RJ45 100M Base-TX Ethernet | Network |
| Audio cable 1 Input: impedance 35k; amplitude 2V [p-p] 1 output: impedance 600; amplitude 2V [p-p] |
Audio I/O |
| 1/1 | Alarm I/O |
| DC 12V±25%, PoE (IEEE 802.3af) Power consumption: Max 9.0W |
Power |
| 5.5mm coaxial power plug | Power Interface |
| 245× 86 × 85mm (9.6” × 3.4” × 3.3”) | Dimensions (Ø x H) |
| 0.87kg(2.03lb) | Weight |
| Metal | Material |
| -30°C ~ 60°C (-22°F ~ 140°F), Humidity: 95% RH (non-condensing) | Working Environment |
| 4KV | Surge protection |
| IK10 | Vandal Resistant |
| IP67 | Ingress Protection |
| Supported | Reset Button |
